Sonoff SV Safe Voltage WiFi Smart switch module

Sonoff SV is a low voltage switch. The low voltage light switch supports 5-24V power supply. Power supply separation enables it to control both AC and DC power, although some welding is required for this purpose.


All product prices include VAT.
Note: Guest users see prices with estimated VAT amount. The payable price with your local value-added tax amount will be calculated based on your shipping address, added at checkout or set in your user profile.

Brand:
Sonoff
Factory SKU ID:
SV
Supported protocols:
Wi-Fi
in stock (30+ pcs)
8.09
Details

Sonoff SV is a low voltage switch. The low voltage light switch supports 5-24V power supply. Power supply separation enables it to control both AC and DC power, although some welding is required for this purpose. It has GIPO reserved to support secondary development. This product does not have 433 RF function and shell.

Sonoff SV low voltage WiFi switch is an affordable device that provides customers with smart home control. The low voltage WiFi switch is a WiFi based wireless switch that can connect to a wide range of appliances. Sonoff SV low voltage remote switch transmits data to a cloud platform through the WiFi router, which enables customers to remotely control all the connected appliances, via the mobile application eWeLink. The cloud server of Sonoff SV is Amazon AWS global server.

Sonoff SV low voltage wireless remote switch makes all home appliances smart. As long as the mobile has network, customers can remotely control the appliances by turning them on/off from anywhere at any time. Another feature available is to set timing schedules for the appliances, which can include countdown, scheduled on/off, and can thus, help customers maintain an easy life.

The mobile application eWeLink enables customers to control the appliances easily. The iOS version of the application can be downloaded in App Store while the Android version in Google Play.

ESP8266 Datasheet

Wiring:

Features:

  • Remote ON/OFF–Turn electrical devices on/off from anywhere
  • LAN Control –Turn on/off the device even when WiFi has no Internet access
  • Low Power Supply–5-24V DC low voltage input
  • App Support –Free iOS and Android mobile App eWeLink
  • Sync Status–Real-time device status provided to App
  • Timing–Set scheduled/countdown timers to turn on/off at specified time, supports max 8 enabled schedule/countdown timers
  • Share Control– Control your smart home together with your family
  • Scene–Turn on/off a gang of devices with one tap
  • Smart Scene–Triggered on/off by temp, hum or other environmental conditions from sensor
  • Compatibility –Works perfectly with Amazon Alexa, Google Assistant, IFTTT, Google Nest
  • Reserves GIPO to support secondary development

Specifications

  • Power supply: 5~24V
  • Weight: 15g



Works With Amazon Alexa

This product works with Amazon Alexa. You can ask Alexa to control the device with the following voice commands. Please note that only US/UK English and German voice commands are supported now.

Try out these phrases ( {deviceName} should be the name of your device):

Alexa, turn on {deviceName}

Alexa, turn off {deviceName}

Alexa, turn {deviceName} off

Alexa, turn {deviceName} on

Alexa, schalte Gerätename ein

Alexa, schalte Gerätename aus

For detailed tutorial, please click here.



Info
Product type:
smart WiFi relay
Colour:
without outer protective cover
Device power supply:
5V-24V DC
Wiring:
5V-24V DC
DIN rail compatible:
no
Embedded relay:
yes
Dimmer feature:
no
Power consumption metering:
no
Number of gangs / circuits:
1
Rated voltage (output):
5V-24V DC, 90-250V AC (max. 10A), max 30V DC
Rated current (output):
10A
Physical on/off button on device:
no
External switch supported:
no
2-way or 3-way switching:
no
Momentary switching (inching):
yes
Surge protection:
no
Overheat protection:
no
Wi-Fi:
yes
Wi-Fi standards:
802.11 b/g/n (2.4GHz)
Zigbee:
no
RF transmitter / receiver:
no
Bluetooth:
no
Controllable from internet:
yes
Manufacturer smartphone app:
yes, free app: eWeLink (Android, iOS)
Web admin interface:
on/off mode (only with subscription, Premium feature)
Voice control:
Amazon Alexa and Google Assistant compatible
Cloud mode:
default mode is connecting to the eWeLink cloud
LAN mode:
yes, if the connection with the eWeLink cloud is disconnected, limited features
REST API support:
no
MQTT support:
no
Supported integrations:
Amazon Echo, Echo Dot, Amazon Tap, Google Home, Google Nest, IFTTT (IFTTT integration with subscription, Premium feature), REST API
Schedulers, timers:
yes, 8 timings on the device in offline mode, (loop control supported), any further timing can be run from the cloud in online mode
Notification functions:
eWeLink app notification on smartphone
History:
yes: on/off history in the app
Weight:
20 g/pcs
